Fiber   Diameter

Cladding   Diameter: 80-150 um; Coating Diameter: 100~1000 um

Fiber   Cleaver Length

5-16mm

Applicable   fibers

SM, MM, DS, NZDS,   G655,G657 and SM (ITU-T G.652),

MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T

G.655), IT-657A,   IT-G657B;0,25mm, 0,9 mm, 2.0mm, 3.0 mm, FLAT (indoor cable)

Splice   loss

0.01dB(MM)、0.02dB(SM)、0.05dB(DS/NZDS/G.655/G.657)

Return   loss

60dB

Tension   test

2.0N

Protection   sleeve length

25mm、40mm、50mm

Splicing   program

6 Set program and   74 user programable program

Language

Chinese, English,French,Russia,Spanish.....

Alignment

Core Alignment(PAS   Technology)

Interface

USB, suitable for   data download and software update

Splice   Memory

Store 8000 groups of splice result and 200 splicing pictures

Electrode   Span

At least 5000   times

Operating   Temp

-18℃～50℃

Storage   Temp

-40℃~80℃

Window   Protection

Max. wind   velocity of 15m/s

Power   Supply

Internal   Li-Battery, 12V/6.8AH  ,AC input   voltage 100 to 240V

Dimension

152mm（L）*142mm（W）*145mm（H）

Weight

1.98KG(Include   battery)
